ESP 120-16AFeatures & BenefitsVery low let-through voltage (enhanced protection to IEC/BS EN 62305) between all sets of conductors (phase to neutral, phase to earth, neutral to earth – Full Mode protection) allowing continuous operation of equipment.Repeated protection in lightning intense environmentsCompact size for easy incorporation in the protected systemRemoveable DIN rail foot for simple clip-on mounting to top hat DIN rails (unboxed versions)Colour coded terminals give a quick and easy installation check – grey for the dirty (line) end and green for the clean endAvailable ready boxed to IP66 for use in dirty or damp environments (protectors with /BX suffix)Robust housing and substantial earth stud fixing holes ready for flat mountingMaintenance freeMains Power Protection Combined Type 2 and 3 tested protector (to BS EN 61643) for use on low current (up to 5 or 16A) single phase systems to protect connected electronic equipment from transient overvoltages on the mains supply, e.g. fire/intruder alarm panels.Protectors with /BX suffix come ready boxed, to IP66, for use in dirty or damp environments.Installation Connect in line with the power supply usually either within the equipment panel (or for CCTV cameras, in an enclosure close by), or on the fused connection that supplies equipment.To protect equipment inside a building from transients entering on an outgoing feed (e.g. to CCTV cameras or to site lighting) the protector should be installed as close to where the cable leaves the building as possible.Unless already boxed, protectors should be installed either within an existing cabinet/cubicle or in a separate enclosure.
